₹9,430.00 Excluding GST
Available in Stock
Product Details:
| Product | Description |
|---|---|
| Brand | Autonics |
| Model No. | E50S8-1000-3-T-1 |
| Series | E50S Series Shaft Type of Incremental Rotary Encoder |
| Diameter |
50mm, Shaft type
|
| Shaft Diameter | 8mm |
| Pulse/Resolution(P/R) | 1000 |
| Output Phase | A, B, Z |
| Output | Totem pole Output |
| Power Supply | 5-24VDC |
|
Max. Response Frequency
|
300kHz |
|
Insulation Resistance
|
Min. 100MΩ |
|
Dielectric Strength
|
750VAC 50/60Hz for 1 Minute |
|
Connection
|
250mm Connector Cable type |
|
Shaft Loading
|
Radial : 10kgf
Thrust : 2.5kgf |
|
Vibration
|
1.5mm Amplitude
|
| Shock | Approx. Max. 75G |
| Ambient Temperature | -10 to 70°C, Storage : -25 to 85°C |
| Ambient Humidity | 35 to 85%RH, Storage : 35 to 90%RH |
| Protection | IP50 |
| Unit Weight | Approx. 275g, Connector Type : 180g |
Above specifications mentioned are for quick reference only. Actual technical details has to be obtained from below catalog.
