Model 1603A-01 Honeywell Torque Transducers

Available on order

For Bulk requirement, Kindly click on enquiry now button

Product Details:

Product	Description
Brand	Honeywell
Model No.	Model 1603A-01
Torque range	Varies on application; consult factory
Frequency response	dc to 1000 Hz
Sensitivity (transmitter)	300 microstrain
Number of channels	1 to 3 (Torque, RPM, HP)
Sampling rate	5 kHz
Receiver readout display type	3.5 digit 7 segment red LED

Above specifications mentioned are for quick reference only. Actual technical details has to be obtained from below catalog.

Description

Model 1603A-01 Honeywell Torque Transducers

DESCRIPTION

The model 1603A and 1603A-01 power measurement system is
identical to the model 1602A system except for the elimination of
the cover over the shaft sensor unit which enables installation in
tight spaces such as under existing covers or deck plates. The
system fits shaft sizes from 63,5 mm to 391 mm [2.5 in to 15.4 in]
in diameter. The system has an electronics readout assembly in
a water tight enclosure. These units together provide means for
measuring shaft torque and RPM. Digital readouts are available
to display torque, RPM and computed horsepower. Built-in calibration check circuitry can be activated at any time to verify that
all local displays and outputs are functional. Enhanced stability
and reduced maintenance are the payback for selecting this
system. The model 1603A and 1603A-01 systems can be used
in a variety of potential applications including fuel conservation
programs, hull and propeller fouling, power plant monitors and
sea trial torsion meters.
