GLAB01A2B Honeywell Limit Switch

Product Details:

Product Description
Brand Honeywell
Model No.
GLAB01A2B
Certifications CE, CCC1, CSA, UL
Conforming to standards IEC/EN 60947-5-1, EN45545-2 (GLA/GLF Series), EN 61373
Housing material Electrostatic epoxy coated zinc
Actuators Side rotary, top pin plunger, top adjustable plunger, top roller plunger, top roller lever, wobble stick (multi-directional) actuator, cat whisker (multi-directional) actuator
Termination 0.5-14 NPT; PG 13,5; M20; G 1/2 (PF 1/2); Deutsch style 4-pin connector; Micro-change connector; Mini-change connector; Pre-cabled
Contact options* 1NC/1NO, 2NC, 2NO, 2NC/2NO, 2NC/2NO sequential, 2NC/2NO center neutral
Contact type Snap action, slow action break-before-make (BBM), slow action make-before-break (MBB), slow action
Contact material Silver alloy (standard), gold-plated (low-energy applications)
Utilization category ac15, A300/A600; dc13, Q300
Rated operational voltage (Ue) 240 Vac, 600 Vac, 250 Vdc

Above specifications mentioned are for quick reference only. Actual technical details has to be obtained from below catalog.

Categories: , Tags:

Description

GLAB01A2B Honeywell Limit Switch

Honeywell’s MICRO SWITCH GLA Limit Switch Series is designed to global EN50041 standards and well suited for worldwide applications. The modular design (heads/actuators, bodies, and contact blocks) of the limit switch allows for rapid response to meet customer applications. The rugged die-cast metal housing of the switch is ideal for indoor and outdoor applications where a degree
of IP or NEMA enclosure sealing is required. Normally closed snap-action contacts and normally closed slow action contacts are positive opening.
