BZV7-2RN2-PG Honeywell Limit Switch

Product Details:

Product Description
Brand Honeywell
Model No.
BZV6-2RQ
Type Limit Switch
Actuators top pin plunger (boot sealed or standard type);
inline roller plunger (boot sealed or standard type);
cross roller plunger (boot sealed or standard type);
roller lever adjustable (boot sealed or standard type);
one-way roller lever adjustable (boot sealed);
coil spring wobble (boot sealed)
Enclosure type diagonal side mount with single conduit (E7 type);
diagonal side mount or side mount with single conduit (E7S type),
side mount with double conduit (E9 type)
flange mount with single conduit (V7 type)
Housing material electrostatic epoxy coated aluminum
Termination threaded conduit, 20 mm or PG 13,5
Sealing actuator with boot seal: IP65
actuator (QN8 style) with internal plunger seal: IP65
actuator without boot seal or internal plunger seal: IP50
Switching options SPDT (snap-action contacts) 1NC/1NO, same polarity
DPDT (snap-action contacts) 2NC/2NO, each pole same polarity
Operating temperature -30 °C to 70 °C [-22 °F to 158 °F]
Electrical rating see tables 2 and 3
Agency certifications EN/IEC 60947-5-1 (all Series); CSA file 15775 (BZ prefix only)

Above specifications mentioned are for quick reference only. Actual technical details has to be obtained from below catalog.

Categories: , Tags:

Description

BZV7-2RN2-PG Honeywell Limit Switch

Honeywell MICRO SWITCH™ E7/V7 Series medium duty limit switches are designed for a wide variety of indoor and outdoor applications. Typical applications include equipment for commercial, industrial, and transportation industries. The electrostatic applied epoxy coating to the aluminum housings enhances the durability of the product in most applications. The E7/V7 family of switches incorporates the Honeywell MICRO SWITCH™ BZ switch element which has the reliable snap-spring mechanism with more than 60 years of proven service. The sealed (plungers with boots) E7/V7 Series are preferred for applications where there could be exposure to liquid and/or particulate environments. The unsealed E7/V7 Series are ideal for applications where there will not be exposure to liquid or dust environments. The compact size of the limit switch permits installation where there is limited space available on equipment.
