411SX21-T Honeywell Micro Switch

Available on order

2,165.00 Excluding GST

For Bulk requirement, Kindly click on enquiry now button



Product Details:

Product Description
Brand Honeywell
Model No. 411SX21-T
Differentiator low operating force to 0,147 N [15 g] max; sensitive differential travel as low as 0,025 mm [0.001 in] max.;
power load switching capability to 7 A
Ampere rating 1 A to 7 A
Circuitry SPDT, SPNO
Operating force 0.71 oz to 6 oz
Termination quick connect, solder, pcb
Actuator pin plunger, straight lever, roller lever, simulated roller lever, offset flag lever, crossed roller lever
Voltage 125 Vac, 250 Vac, 28 Vdc
Agency approvals UL, CE, CSA, ENEC, MIL-PRF-8805, FAA-PMA
Agency file information UL: E12252; CSA: LR41372
Operating temperature -54°C to 121°C [-65°F to 250°F]; select catalog listings 204°C [400°F]
Contacts silver, gold-plated, bifurcated gold
Housing phenolic or thermoplastic polyester
Sealing not weather sealed
Mechanical life up to 10,000,000 operations for 11SX Series
up to 1,000,000 operations for 1SX Series
Size 10,2 mm H x 5,08 mm W x 12,7 mm L [0.4 in H x 0.20 in W x 0.5 in L]
Type PIN PLUNGER

Above specifications mentioned are for quick reference only. Actual technical details has to be obtained from below catalog.

Honeywell V7-1C17E9-201 Micro Switch

Description

411SX21-T Honeywell Micro Switch

The industry-defining name in snap-action switches, Honeywell MICRO SWITCH™ premium subminiature switches are
designed for repeatability and enhanced product life. The MICRO SWITCH™ SX Series delivers consistent performance
within a range of conditions.
Offering enhanced repeatability, the MICRO SWITCH™ SX Series’ lower operating force provides for application versatility.
Like the MICRO SWITCH™ SM Series, the SX Series (which is a smaller package) offers gold contacts for low energy
switching and bifurcated gold contacts for maximum reliability. Bifurcated contacts provide parallel redundancy within the
SX switch.



FEATURES

  • LONG LIFE
  • APPLICATION FLEXIBILITY
  • INDUSTRY-LEADING TEMERATURE RANGE
  • COMPACT AND ROBUST
  • EASILY CONTROLS LOW-VOLTAGE DC APPLICATIONS
  • GLOBAL APPROVALS
