SS360ST Honeywell Hall Effect Sensor

Description

 SS360ST Honeywell  Hall Effect Sensor , SS360NT, SS360ST, SS360ST-10K, SS460S, SS460S-T2, SS460S-T3, and SS460S-LP High Sensitivity Latching Digital Hall-Effect Sensor ICs are small, sensitive and versatile devices that are operated by the magnetic field from a permanent magnet or an electromagnet. SS360ST Hall Effect Sensor are designed to respond to alternating North and South poles. The SS360NT is turned on by a North pole while the SS360ST, SS460S, SS460S-T2, SS460S-T3, and SS460S-LP are turned on by a South pole. These sensor ICs offer reliable switching points with a high magnetic sensitivity of 30 G typical (55 G maximum). They do not use chopper stabilization on the Hall element, providing a clean output signal and a faster latch response time when compared to competitive high sensitivity Hall-effect latching sensor ICs which do use chopper stabilization. These products offer reverse polarity protection, deliver a stable output over a -40°C to 150°C temperature range, and can accept any dc supply voltage from 3 Vdc to 24 Vdc. For brushless dc motor manufacturers who need latching sensors with reliable, consistent performance for more efficient and smaller designs, Honeywell’s High Sensitivity Hall-Effect Latching Digital Sensor ICs respond to low magnetic fields and offer consistent repeatability while delivering faster response times to a change in magnetic field for better motor efficiency.

FEATURES
• Fastest response time in its class
• No-chopper-stabilization
• High sensitivity
• Latching magnetics
• Wide operating voltage range of 3 Vdc to 24 Vdc
• Built-in reverse voltage
• Durable design
• RoHS-compliant material meets Directive 2002/95

POTENTIAL APPLICATIONS
Industrial/commercial
• Brushless dc motor commutation
• Speed and RPM sensing in electric motors and fans
• Tachometer, counter pickup
• Robotics control
• Flow-rate sensing for appliances
Transportation
• Brushless dc motor commutation
• Electronic window lift, anti-pinch power window systems
• Vehicle convertible roof position
Medical
• Medical equipment using electric motors
