Product Details:
| Product | Description |
|---|---|
| Brand | Honeywell |
| Model no. | SLP-H |
| Contact Type, Contact Material | SPDT, Silver Alloy (Gold plated contact available) |
| Actuator | Top Roller Lever |
| Operating Speed | 0.05mm ~ 0.5m/s |
| Operating Frequency | Mechanically：120 ops/min, Electrically：30 ops/min |
| Rated Current/Voltage | Silver: 5A/250VAC or 5A/30VDC Gold plated: 0.1A/250VAC or 0.1A/30VDC |
| Contact Resistance | <25mΩ (initial) |
| Insulation Resistance | >100MΩ@500V DC |
| Dielectric Strength | 1000VAC for 1 min between current carrying parts 2500VAC for 1 min between non-current carrying part |
| Service Life | Mechanically：5,000,000 ops Electrically：500,000 ops at maximum rating |
| Shock | Free position:<10G, Maximum position：<30G |
| Vibration | 10 to 55 Hz, 1.5 mm double amplitude (excluding spring coil type) |
| Operating Temperature | -30 to 80℃ |
| Certification | CE, CCC |
| Degree of Protection | IP67 |
FEATURES
Asia standard dimension
Design for small mounting space.
10A current capacity
Long mechanical life 1×107 operations
Wide range of actuators available
UL, cUL, CCC, CE approved
IP65 (standard type) and IP67 (precision type) Rated
Precision type SLP has built-in IP67 rated cable gland
(also available in M12 quick connector type)
