SL-H Honeywell Micro Switch

For Bulk requirement, Kindly click on enquiry now button



Product Details:

Product Description
Brand Honeywell
Model no. SL-H
Contact Type, Contact Material SPDT, Silver Alloy
Actuator Plunger
Operating Speed 0.05mm ~ 2m/s
Operating Frequency Mechanically:120 ops/min, Electrically:30 ops/min
Rated Current/Voltage 10A/250VAC (EN60947-5-1)
Contact Resistance <25mΩ (initial)
Insulation Resistance >100MΩ@500V DC
Dielectric Strength 1000VAC for 1 min between current carrying parts
2500VAC for 1 min between non-current carrying part
Service Life Mechanically:5,000,000 ops
Electrically:500,000 ops at maximum rating
Shock Free position:<10G, Maximum position:<30G
Vibration 10 to 55 Hz, 1.5 mm double amplitude (excluding spring coil type)
Operating Temperature -20 to 60℃
Certification CE, CCC, UL (E313809)
Degree of Protection IP64

Above specifications mentioned are for quick reference only. Actual technical details has to be obtained from below catalog.

brochure

Description

SL-H Honeywell Micro Switch

FEATURES

Asia standard dimension

Design for small mounting space.

10A current capacity

Long mechanical life 1×107 operations

Wide range of actuators available

UL, cUL, CCC, CE approved

IP65 (standard type) and IP67 (precision type) Rated

Precision type SLP has built-in IP67 rated cable gland

(also available in M12 quick connector type)



Applications:

General Machinery
Conveyer, Transportation Equipments
Specialty Machinery
Packaging Mechinery
