₹1,232.00 Excluding GST
Product Details:
| Product | Description |
|---|---|
| Brand | Autonics |
| Model | PSN30-15DP |
| Wire type and power | DC 2-wire type 12-24VDC |
| Sensing distance | 15mm |
| Hysteresis(distance) | Max. 10% of sensing distance |
| Standard sensing target | 12×12×1mm(iron) |
| Setting Distance | 0-10.5mm |
| Response frequency | 200Hz |
| Current Cunsumption | Max 10mA |
| Control output | Max 200mA |
| Material | Brass(nickel plated) |
| Cable Standard ( material ) | Standard cable |
| Protection structure | IP67 |
| Approval | CE |
| Shock | 500m/s2 |
| Environment Ambient temperature | -25 to 70 Deg C. |
| Environment Ambient humidity | 35 to 95% RH |
| Dielectric Strength | 1500 VAC |
| Residual voltage | Max. 1.5V |
| Weight | Approx. 111g |
Above specifications mentioned are for quick reference only. Actual technical details has to be obtained from below catalog.
PSN30-15DP Autonics Proximity Sensor
