SIGNAL ON DELAY, POWER ON DELAY, FLICKER, INTERVAL, SIGNAL OFF DELAY, ON-OFF DELAY, INTEGRATION TIME
Power supply
100-240VAC~ 50/60Hz
Time operation
POWER ON START
SIGNAL ON START
External Power Supply
Max. 12VDC ±10%, 100mA
Signal Input Method
Voltage input(PNP), No-voltage input(NPN)
Max. Counting Speed
1, 30, 1k, 5k, 10k [cps]
Min. signal Width
1ms/20ms
Memory Protection
Approx. 10 years
Setting range
0.001 sec to 9.999 sec, 0.01 sec to 99.99 sec, 0.1 sec to 999.9 sec, 1 sec to 9999 sec, 1 sec to 99 min 59 sec, 0.1 min to 999.9 min, 1 min to 9999 min, 1 min to 99 hour 59 min, 1 hour to 9999 hour
Control output Type
1-stage preset
Control output Relay
SPDT (1c): 1
Control output NPN open collector
1
Protection structure
IP65(front panel)
Counter Counting range
-999 to 9999
Counter Scale
Decimal point up to third digit
Counter Min. input signal width
RESET: Selectable 1ms/20ms
Timer Min. input signal width
INA, INH, RESET: Selectable 1ms/20ms
Environment Ambient temperature
-10 to 55℃, storage: -25 to 65℃
Environment Ambient humidity
35 to 85% RH, storage: 35 to 85% RH
Weight
Approx. 212g (approx. 159g)
Above specifications mentioned are for quick reference only. Actual technical details has to be obtained from below catalog.
