Name: BZ-R-A2 Honeywell Micro Switch
SKU: 65209
Price: 590.00 INR
Availability: InStock

BZ-R-A2 Honeywell Micro Switch

₹590.00 Excluding GST

Available in Stock

For Bulk requirement, Kindly click on enquiry now button

Product Details:

Product	Description
Brand	Honeywell
Model Number	BZ-R-A2
Ampere rating	15 A
Circuitry	SPDT
Operating force N [ oz]	1,95 to 2.5 [7 to 9]
Release force min. N [ oz]	1,11[4]
Pretravel max. mm [in]	0,30 [0.012]
Overtravel min. mm [in]	0,13 [0.005]
Differential travel mm [in]	0,005 to 0,008
Actuator	pin plunge
Voltage	125 Vac, 250 Vac, 125 Vdc, 250 Vdc
Agency approvals	UL, CSA, ENEC, CE (varies by specific model)
Operating temperature	-55 °C to 85 °C [-67 °F to 185 °F]
Housing	general purpose phenolic
Sealing	Environment sealing option available (options for IP64 Sealing)
Dielectric strength	2000 V between each terminal and ground
Contact resistance	15 m Ohm max.(initial)

Above specifications mentioned are for quick reference only. Actual technical details has to be obtained from below catalog.

Description

BZ-R-A2 Honeywell Micro Switch , Accurate, reliable, and repeatable, MICRO SWITCH™ BZ/BA/BM/BE Series features precise operating characteristics and enhanced life. These premium, large snap-action switches offer precision operation and sensitive differential
travel.
Utilizing state-of-the-art manufacturing processes and quality controls, Honeywell has engineered premium, large snap-action switches that meet various international agency requirements. Some models have military qualifications.
MICRO SWITCH™ BZ/BA/BM/BE Series are often used for precision on/off applications, as well as end of limit, presence/absence, and manual operator interface functions. Their engineered design is suitable for various application needs. Configured options with BZ, BA, BM, and BE switches provide a wide variety of operating and interface characteristics.
The MICRO SWITCH™ 6AS Series consists of two large premium BZ/BA/BM/BE snap-action switches ganged
together and actuated by a single actuator. Field adjustable operating point is an option for one or both switches.
