5NF (AF508-W0C) City Technology Nitric Oxide Sensor

Available on order
For Bulk requirement, Kindly click on enquiry now button

Product Details:

Product Description
Brand City Technology
Model Number 5NF (AF508-W0C)
Nominal Range 0-1000ppm
Maximum Overload 5000ppm
Internal Filter To remove effect of SO2
Internal Filter Life 25,000 ppm hours
(1000ppm SO2
at 200ml/min)
Expected Operating Life Three years in air
Output Signal 0.10 ± 0.02 µA/ppm
Resolution 1ppm
Operating Temperature
Range
-20°C to +40°C
Pressure Range Atmospheric ± 10%
Pressure Coefficient 0.01 % signal/mbar
T90 Response Time < 30 seconds
Relative Humidity Range 15 to 90 % non-condensing
Typical Baseline Range
(pure air)
0 to +12ppm equivalent
Maximum Zero Shift
(+20°C to +40°C)
30ppm equivalent
Long Term Output Drift <2% signal loss/month
Recommended Load
Resistor
10Ω
Bias Voltage +300mV
Repeatability 2% of signal
Output Linearity Linear

Above specifications mentioned are for quick reference only. Actual technical details has to be obtained from below catalog.

Description

5NF (AF508-W0C) City Technology Nitric Oxide Sensor

CiTiceLs may exhibit a response to certain gases in a sample other than the target gas. The table below shows the
typical response of 5NF sensors to a number of common cross-interfering gases. The figures are expressed as a
percentage of the primary sensitivity (i.e. nitric oxide = 100%).
