201EN1-1 Honeywell Limit Switch

Available on order

42,367.00 Excluding GST

For Bulk requirement, Kindly click on enquiry now button



Product Details:

Product Description
Brand Honeywell
Model No. 201EN1-1
Description Environmentally sealed military qualified limit switch series (MIL-PRF-8805)
Housing & bushing material 300 Series stainless steel
Contact material Silver alloy, gold plated, gold bifurcated
Mechanical endurance 25,000 cycles min.
Electrical endurance 25,000 cycles min. @ rated load
Circuitry 1PST (one-pole single throw) to 6PDT (six-pole double throw); reference Figure 2, page 3
Dielectric strength (initial) 1000 V RMS; 500 μA max. leakage
Insulation resistance (initial) 500 Vdc; 1000 Megohms min.
Environmental sealing Symbol 4, resilient seal per MIL-PRF-8805
Temperature range (std.) -54 °C to 85 °C [-65 °F to 185 °F]
Shock Symbol M (100 g) per MIL-PRF-8805
Vibration Symbol 1, 10 g peak (10 Hz to 500 Hz)

Above specifications mentioned are for quick reference only. Actual technical details has to be obtained from below catalog.

Honeywell V7-1C17E9-201 Micro Switch

Description

201EN1-1 Honeywell Limit Switch

The Honeywell MICRO SWITCH™ Series of EN limit switches are bushing mount designed, manufactured, and qualified to MIL-PRF-8805 standards. These products provide a durable switch for commercial and military aircraft as well as commercial and military ground-based equipment. Other applications include off-road equipment where severe environments are encountered.
The EN Series of switches have proven to deliver consistent and reliable operation in harsh environments on critical applications for more than 65 years.
