ZW50F90AW1 Honeywell Micro Switch

For Bulk requirement, Kindly click on enquiry now button

Product Details:

Product	Description
Brand	Honeywell
Model No.	ZW50F90AW1
Actuator	Pin plunger
Circuitry/Contact Material	SPDT/ Silver
Elect. Rating Spec.	6 A
Termination	Wire leads, bottom exit (500 mm)
O.F. max. N [g]	2,00 N [203 g]
Housing material	case, PBT (polyester); cover, PBT (polyester

Above specifications mentioned are for quick reference only. Actual technical details has to be obtained from below catalog.

Description

ZW50F90AW1 Honeywell Micro Switch

Honeywell’s MICRO SWITCH™ ZW Series is a sealed subminiature snap action switch from the Honeywell family of
Z Series subminiature basic switches. Although small in size, the ZW Series is rated for controlling electrical loads
ranging from logic level/computer-based circuits to power-duty switching (up to 6 amps and up to 250 Vac).
Switches supplied with integral wire leads are sealed to IP67 and are suitable for applications where a switch
assembly would be exposed to liquids or particulate contaminates in the environment from indoor or outdoor use.
A wide variety of stainless steel levers are available and when combined with the subminiature package size,
can adapt the switch for many different applications. The ZW Series is certified to UL, cUL, ENEC, and CQC for
worldwide use
