TARS-HCASS Honeywell Pressure Transducer Accessories

For Bulk requirement, Kindly click on enquiry now button

Product Details:

Product  Description
Brand Honeywell
Model TARS-HCASS
Operating temperature -40°C to 85°C [40°F to 185°F]
Storage temperature -40°C to 105°C [40°F to 221°F]
Housing PBT thermoplastic
Random vibration 10 hours at 25 Grms per MIL-STD-810, Method 514.7,
Procedure I, Annex D, Category 20, 5 Hz to 500 Hz (flat spectrum)
Mechanical shock 50 g 11 ms half-sine, 3 each direction, 18 total, pulse per MIL-STD-202, Method 213
Chemical compatibility diesel fuel, hydraulic oil, ethylene glycol, motor oil, brake fluid, urea nitrogen, liquid lime,
NPK fertilizer, ammonium hydroxide, alkaline degreaser, transmission oil, power steering
fluid, and axle oil
Moisture resistance per MIL-STD-202, Method 106 (10 cycles, 24 hours/cycle)
Thermal shock 250 cycles, -40°C to 85°C, 73 min dwell
Salt spray 5 % salt solution, 96 hours
Ingress protection IP67, IP69K (DIN40050-1993) with mating connector installed
RoHS compliant
REACH compliant
UV rating housing material meets outdoor suitability requirements per UL746C F1 rating

Above specifications mentioned are for quick reference only. Actual technical details has to be obtained from below catalog.

brochure

Categories: , Tags:

Description

TARS-HCASS Honeywell Pressure Transducer Accessories

The Transportation Attitude Reference System (TARS-IMU) is a packaged sensor array designed to report vehicle angular rate, acceleration, and attitude data for demanding applications in industries such as heavy-duty, off-highway transportation. The TARS-IMU enables autonomous vehicle characteristics and enhances efficiency and productivity by reporting key data required to automate and
monitor movements of vehicle systems and components. The sensor fusion algorithm may be customized for specific vehicle applications via on-board firmware, allowing movement data to be filtered for extraneous environment and vehicle movements. With two sensor models for different power levels, the TARS-IMU accommodates both 5 V and 9 V to 36 V vehicle power systems. Communication is transmitted using industry standard CAN J1939 connectivity. As a standard, TARS-IMU is calibrated on aerospace grade rate tables at the factory to provide enhanced calibration consistency between units.
